Carbon-fiber frame
The sculpted frame balances a lightweight target with a distinctive silhouette—the defining visual and structural language of NIM.
PREMIUM URBAN E-BIKE
NIMBY QERYU / 01
Lightweight carbon, effortless mid-drive power and a full fold—made for fast-moving city life.
* 42 lb (19 kg) weight and 50 mi (80 km) range are targets. Final figures are subject to production-model testing.
NIM / CITY SERIES
90 N·m66 lb-ftPeak torque
19 kg*42 lb*Target bike weight
25 km/h / 15.5 mph15.5 mphAssist cutoff speed
80 km*50 mi*Target assisted range
01 / DESIGNED TO MOVE
Light by design.
Light by design.
Built for the city.
A sculpted carbon frame keeps NIM agile in traffic, easy to carry and compact to store—without losing the natural feel of a bicycle.
01Fully folding frameTrunk-ready
02Folding stem and pedalsCleaner storage
03Deep green metallic finish + black componentsUnderstated premium character
CITY, REFRAMED
From the daily commute
to a wider life.
Compact 20-inch wheels turn quickly through traffic, while the carbon frame keeps the ride light, composed and unmistakably NIM.
MID-DRIVE POWER
Natural power.
Instant response.
Centered low in the frame, the SC31 mid-drive responds to pedal input in under 20 ms—smooth off the line, confident on climbs and natural in traffic.
PEAK TORQUE90 N·m66 lb-ft
MAX ASSIST RATIO350%Rated 200%
Sensor response20 ms
Motor water resistanceIPX6
ENGINEERED DETAILS
Every detail,
made for everyday ease.
Less upkeep, more everyday value: a cleaner belt drive, confident hydraulic braking and a lightweight carbon structure.
Low-maintenance belt drive
Cleaner and quieter than a chain, the belt drive pairs with a 3-speed internal hub to reduce everyday maintenance.
Front and rear hydraulic disc brakes
Hydraulic discs deliver clear, progressive braking, while folding brake levers help reduce the bike's stored footprint.
DAILY SCALEEasy to step through.
Easy to step through.
Natural to control.
20-INCH AGILITY
Quick through traffic. Easy to park.
Fold.
Go.
Go.
A fully folding frame, stem and pedals make more room in lifts, car trunks and compact indoor spaces.
CONNECTED RIDE
Tap to connect.
Your ride, always in view.
The prototype supports Bluetooth, with NFC, app and OTA capabilities reserved. Final software features and interface are subject to the production version.
01
Bluetooth connectivity
Connect ride services and vehicle status to your phone.
02
NFC proximity unlock
An NFC key tag is visible on the prototype; production interaction is to be confirmed.
03
APP / OTA ready
Reserved for ride data, vehicle settings and future updates.
SPECIFICATIONS
Specifications
Key specifications are organized clearly by category for quick review.
Bike
| Brand / Model | QERYU NIM |
|---|---|
| Positioning | Premium urban commute / refined folding e-bike |
| Frame material | Carbon fiber |
| Folding system | Fully foldable, trunk-ready |
| Wheel size | 20 in |
| Bike weight | 19 kg / 42 lb |
| Assisted range | 80 km / 50 mi |
Power
| Motor | SC31 mid-drive motor |
|---|---|
| Rated / Peak power | 250 W / 500 W |
| Rated / Peak torque | 50 N·m / 90 N·m (37 / 66 lb-ft) |
| Rated / Max assist ratio | 200% rated / 350% max |
| Torque-sensor response | < 20 ms |
| Assist cutoff speed | 25 km/h / 15.5 mph |
| Motor water resistance | IPX6 |
| Battery | 36 V · 7 Ah / 10 Ah |
Drivetrain & brakes
| Drive system | Belt drive |
|---|---|
| Rear hub | 3-speed internal-gear rear hub |
| Brakes | Front and rear hydraulic disc brakes |
| Brake levers | Foldable design |
| Pedals | Folding pedals |
| Stem | Folding stem |
Smart & durability
| Bluetooth connectivity | Supported |
|---|---|
| Connectivity | UART + NFC + Bluetooth + APP |
| NFC | NFC key tag visible on prototype |
| Motor operating temperature | -20°C to 45°C / -4°F to 113°F |
| Motor noise | < 55 dB(A) |
| Motor design life | 50,000 km / 31,000 mi |
| Motor warranty | 24 months |
Important: 42 lb (19 kg) bike weight and 50 mi (80 km) assisted range are target figures. Actual range varies with load, temperature, terrain, assist level and battery version. EN15194 is in progress (target: Q4 2026); this page does not claim certification.
